Core 110c
Combined with DPA-Q amplifiers and DCS loudspeakers, the Q-SYS Cinema Core 110c provides a cost-effective solution for implementing Q-SYS in cinemas of all sizes. The Q-SYS Cinema Core 110c is ideal for multiple room 5.1/7.1 applications, or as the sole audio system processor for Dolby Atmos installations.
Note: This topic provides an overview of the Core 110c, which is discontinued. For specs and installation instructions, see the Discontinued Products page.
Local I/O Channels |
24 (8 analog in, 8 analog out, 8 analog flex in/out), 16x16 USB audio |
Network Audio Channels |
128 x 128 |
AEC Processors |
4 |
Multitrack Audio Players |
16 (upgradable to 32) |
Local I/O Card Capacity |
N/A (Built-in I/O on this model) |
VoIP Instances |
4 |
Maximum NV-32-H Network Video Endpoints |
32 |
Maximum NL, NM, and QIO Series Endpoints |
32 |
