QIO-24f

The Q-SYS QIO-24f is a network audio endpoint native to the Q-SYS Ecosystem, serving as a set of audio inputs and outputs that enables network-based audio distribution. The form factor of this product facilitates a high density of 24 analog audio connections in a standard 1U rack space, ideal for applications that require a large number of audio connections. The QIO-24f offers eight mic/line input connections, eight FLEX I/O connections that can be used as inputs or outputs, and eight line output connections; along with 8x8 GPIO ports for control. Dual Ethernet connectors provide optional network redundancy, and two of these products can also be installed in a redundant failover pair to guard against unexpected audio interruptions in critical applications.

Note: This topic provides an overview of the QIO-24f. For specifications and installation documentation, see the QIO Series High-density Audio Expanders product page on the Q-SYS website.

  • Native, high-density audio I/O for Q-SYS

  • Eight (8) mic/line level inputs, eight (8) software-definable Flex channels and eight (8) line level outputs

  • Supports both network and peripheral redundancy

  • 1RU form factor

  • 8 x 8 GPIO to integrate third-party device control connectivity

  • Configurable +48 VDC phantom power on inputs

  • Microphone detection on inputs enables monitoring, usage statistics, and failure notifications

  • Integrated relay mute on outputs enables redundant audio output for peripheral redundancy and prevents power-up transients

  • Two (2) gigabit Ethernet ports for redundant networked audio

  • Surface- or rack-mountable

  • QIO-CK redundancy cable kit (sold separately)

These Inventory components are available for the QIO-24f:

  1. Air intake vents

  2. ID button invokes ID feature

  3. ID LED illuminates when ID feature is invoked

  4. POWER on LED

(QIO-24f shown)

  1. LAN ports (dual) - Up to 1 Gbps per port

  2. Exhaust vents (do not block)

  3. AC mains inlet connector - Supports universal (international) mains

  4. General Purpose Inputs (8 pins, 2-9) 0-24VDC analog, potentiometer, TTL digital or contact closure input.

  5. General Purpose Outputs (8 pins, 2-9) Open collector (24V, 0.2A max), with pullups to 3.3V or TTL output

  6. Ground Reference (Pin 10 on each connector)

  7. 12VDC Source (Pin 1 on each connector). Provides up to 0.2A per pin

  1. Mic/Line Inputs (8 channels - orange) - Balanced or Unbalanced plus +48V (P48) phantom power compliant with IEC 61938

  2. Flex Channels (8 channels - blue) - Configurable as Mic/Line Input or Line Output per channel

  3. Line Outputs (8 channels - green) - Balanced or Unbalanced

  4. Exhaust vents (do not block)

Product specifications for the QIO-24f can be found on the QIO Series High-density Audio Expanders product page.
